Air Source Heat Pump Buy China

Leomon Technology is the best manufacturer of air source heat pumps in China. If you need to buy a Chinese air source heat pump, please choose to buy an air source heat pump of the Leomon Technology brand.


Air source heat pump is one of the most economical and environmentally friendly heating and hot water solutions on the market. It can not only help homeowners reduce their carbon footprint, but also significantly reduce heating costs.


Heat pumps use electricity to power compressors and use refrigeration cycles to transfer heat. They can operate normally at outdoor temperatures as low as -15°C.

In the summer, it works like an air conditioner to provide cooling, using refrigerant to transfer heat out of your home.

In winter, the heat pump runs in reverse to provide heating by extracting heat from the outdoor air.


25% of the energy of the heat pump comes from electricity, and 75% of the heat comes from air. Using a heat pump will save you a lot of electricity bills.


Air Source Heat Pump Features:
1). Reliability and excellent performance of world-renowned scroll compressors
2). Efficient and environmentally friendly R134A, R417A or R407C refrigerant, no ozone depletion
3). Intelligent control: microprocessor-based digital controller with LCD display
4). Adjustable water temperature: 25℃-60℃. There is no potential risk of polluting drinking water
5). Blue hydrophilic aluminum fin, anti-corrosion, durable, low maintenance
6). Multiple protections to protect the compressor and heat exchanger
7). Internally threaded copper pipe, higher efficiency
8). Four-way valve ensures reliable defrosting function
9). Alco or Danfoss thermal expansion valve, to more accurately control pressure and temperature to ensure fatigue resistance, thereby prolonging the service life.
10) Safety: Water and electricity are completely isolated, no potential hazards such as flammability, gas poisoning, explosion, fire, electric shock, etc. are associated with other heating systems

Warranty:
1). Passed CE and RoHS certification
2). Service life is about 20 years
3). 2 years warranty, buy with confidence

Heat Pump Components:
1.Silver welding
Silver welding technology makes the unit system more reliable; it is likely that it will avoid refrigerant leakage
2. Intelligent control
Unit adopts intelligent control system: microprocessor-based digital controller, LCD display
3. Shell and tube
Heat Exchanger High-efficiency shell-and-tube water heat exchanger, the highest working water pressure can reach 3.2Mpa
3. Alco Thermal Expansion Valve
Reliability
4. Efficient and environmentally friendly
Refrigerant, does not destroy the ozone layer
5. Low noise fan
Use axial flow fan, with large air volume and low operating noise
6. Air pressure driven water flow control valve
The water flow is controlled by refrigerant pressure to ensure hot water supply at a constant adjustable temperature


Air Source Heat Pump Specifications:

Power range: 8kW, 10kW, 12kW, 15kW, 17kW, 20kW, 25kW, 28kW, 30kW, 35kW, 40kW, 45kW, 55kW, 60kW, 90kW, 100kW, 115kW, etc.


Model
LM-21AE2
Power Supply
380V/3N/50Hz
Max heating current(A)
11.1
Refrigerant
R410A
Noise dB(A)

Exhaust air/Absorb

air max working pressure(Mpa)

4.2/1.5
Rated water temperature
28
Max water temperature
45
Electric shock proof grade
CLASS1
Protection grade
IPX4
Weight(kg)
175
Water connection
40
Net dimensions(L*W*H)
800*800*1105mm
Net dimensions(L*W*H)
920*920*1300mm
Compressor brand/type
Copeland/Scroll
Compressor quantity
1
Evaporater quantity
1
Motor type/quantity
AC MOTOR/1
Motor Power Input
450
Motor roate speed
860
Air discharge way
vertical
Throttle mode
Thermal/EEV
Air side heat excharge
Fin-coil
water side heat excharge
Tianium
