Air Source Heat Pump for Indoor Swimming Pool

An indoor swimming pool heat pump (or air source heat pump) is an efficient, economical and "green" way to heat swimming pool water. In fact, compared with other heating methods, air source heat pumps have the lowest carbon footprint and lowest operating costs.

Air source heat pumps work by "releasing" heat from the surrounding fresh air and using it to heat water. For every unit of electrical energy you power them, you can get up to 5.25 units of heat.

The indoor swimming pool heat pump can provide you with a comfortable swimming pool water temperature throughout the year. They can be used to cool the swimming pool in summer. They can be used to heat the swimming pool in winter. You can use it all year round without worrying about wasting a lot of electricity.

Air Source Heat Pump pool heater characteristics:

1. Copeland scroll compressor has high efficiency, low noise and long life.

2. "All-season" model, which can operate before -10°C

3. Titanium material, corrosion resistant, specially used for swimming pool water.

4. The electronic expansion valve automatically adjusts the refrigerant flow.

5. Galvanized steel sheet, beautiful and corrosion-resistant.

6. Built-in Wi-Fi module.

7. Set and check all parameters, if the heat pump fails, it will protect itself.

8. The heat pump uses environmentally friendly refrigerants: R417A / R407C / R404A.

9. The heat pump is small in size, so ordinary plumbers can easily install it.

10. Precise temperature control

-Heat output: 5KW 8KW 12KW 20KW 24KW 48KW 96KW 145KW 220KW

-Voltage/phase/frequency: 220-240V / 1PH / 50HZ

-Digital LCD controller

-Water flow rate: 3-3.5 cubic meters/hour

-Maximum outlet water temperature: 40ºC

-Sound level: 48 dB (A)

-Water connection: 2 inches

Heat Pump Key Componets:

Smart control: microprocessor-based digital controller with LCD display digital controller

American Compressor: Copeland Scroll has high working efficiency.

PVC Titanium Heat Exchanger:resistance to chemical corrosion and pool corrosion

Low Noise Fan Axial Fans: high wind and low noise

Eco-friendly Refrigerant: without ozone depletion

Silver welding: avoid refrigerant leakage

Warranty:

1. Heat Pumps have CE and RoHS certificates.

2. 1 year warranty

3.1% spare parts are repaired free of charge.

Leomon Technology can design and produce air source swimming pool heat pumps according to customers' special requirements.

Swimming pool heat pump power outputs guidance:

In Ground Pools:

Pool size	Power / kW
24ft x 12ft (7.32m x 3.66m)	12 - 16
28ft x 14ft (8.53m x 4.27m)	12 - 16
30ft x 15ft (9.14m x 4.57m)	15 - 25
32ft x 16ft (9.75m x 4.88m)	23 - 31
36ft x 18ft (10.97m x 5.49m)	23 - 31
40ft x 20ft (12.19m x 6.10m)	30 - 36

Above Ground Pools:

Pool size	Power / kW
12ft diameter (3.66m)	8 - 12
15ft diameter (4.57m)	9 - 16
18ft diameter (5.49m)	9 - 16
20ft x 12ft (6.10m x 3.66m)	9 - 16
24ft x 12ft (7.32m x 3.66m)	15 - 18
30ft x 15ft (9.14m x 4.57m)	15 - 25
33ft x 18ft (10.06m x 5.49m)	23 - 31
