Air to Water Heat Pump Buy

Air to water heat pumps can provide cost-effective heating, cooling and hot water for your home or commercial building. It can help you enjoy a comfortable indoor temperature throughout the year.


Heat pumps obtain heat energy from outside air instead of burning fossil fuels to obtain heat. This will save you 1/3 of the cost of use and help you reduce carbon emissions.


Heat pumps use CO2 as the refrigerant. This allows it to provide hot water at 90°C even at an extremely harsh outdoor temperature of -25°C.


The working principle of air-to-water heat pump:

1. The evaporator extracts heat from the air by forcing liquid to transform into gas.

2. The compressor compresses the gas, thereby increasing its temperature.

3. The condenser exchanges the heat from the gas to the heating system to restore the gas to a liquid state.

4. The expansion valve reduces the pressure of the refrigerant, which initiates evaporation and the cycle restarts.


Air to Water Heat Pump Features:
1). Reliability and excellent performance of world-renowned scroll compressors
2). Efficient and environmentally friendly R134A, R417A or R407C refrigerant, no ozone depletion
3). Intelligent control: microprocessor-based digital controller with LCD display
4). Adjustable water temperature: 25℃-60℃. There is no potential risk of polluting drinking water
5). Blue hydrophilic aluminum fin, anti-corrosion, durable, low maintenance
6). Multiple protections to protect the compressor and heat exchanger
7). Internally threaded copper pipe, higher efficiency
8). Four-way valve ensures reliable defrosting function
9). Alco or Danfoss thermal expansion valve, to more accurately control pressure and temperature to ensure fatigue resistance, thereby prolonging the service life.
10) Safety: Water and electricity are completely isolated, no potential hazards such as flammability, gas poisoning, explosion, fire, electric shock, etc. are associated with other heating systems

Warranty:
1). Passed CE and RoHS certification
2). Service life is about 20 years
3). 2 years warranty, buy with confidence


Air to Water Heat Pump Specifications:

Power range: 8kW, 10kW, 12kW, 15kW, 17kW, 20kW, 25kW, 28kW, 30kW, 35kW, 40kW, 45kW, 55kW, 60kW, 90kW, 100kW, 115kW, etc.


Model
LM050V2
Power supply

220-240/50/1

V/Hz/Ph

Max. heating

capacity(1)

16.5KW
C.O.P(1)
4.48W/W

Heating capacity

Min/Max.(1)

7.59 /16.5KW

Heating power

input Min/Max.(1)

1353/3683W
COP Min./Max.(1)
4.48/5.6W/W
Max. heating capacity(2)
15.5KW
C.O.P (2)
3.58W/W

Heating capacity

Min/Max.(2)

7.13 /15.51KW

Heating power

input Min/Max.(2)

1676/4328W
COP Min./Max.(2)
3.58/4.26WW
Max. cooling capacity(3)
14.7KW
E.E.R(3)
3.48W/W
Max. cooling capacity(3)
6.78/14.73KW

Cooling power

input Min/Max.(3)

1625/4953W
E.E.R Min./Max. (3)
2.97/4.17W/W
Max. cooling capacity(4)
11.6KW
E.E.R(4)
2.61W/W
Max. cooling capacity(4)
5.35/11.63KW

Cooling power

input Min/Max.(4)

1458/4601W
E.E.R Min./Max. (4)
2.53/3.67W/W
Rate current
17.6A
Max current
25.55A
Compressor
Twin rotary-1
Fan Quantity
2Pcs
Fan Airflow
5000m3/h
Fan Rated power
200W

Water side

heat exchanger

Plate heat exchanger
Water pressure drop
23KPA
Piping connection
G1"Inch

Allowable water flow

Min./Rated /Max

0.49/0.79/1.31L/S
Noise level
62dB(A)

Net Dimension

(L*D*H)

1100*490*1350

mm

Net Weight
124KG
