Air to Water Heat Pump Cost
Heat pumps are becoming more and more popular because they can provide
an excellent source of energy-efficient heat and hot water for homes or
offices. If you are looking for heating or cooling equipment, air to water heat
pumps are most likely the energy solution you need because they are not only a green
technology, but also versatile and cost-effective.
There are many factors to consider when buying a heat pump. These
variables mean that installation costs can vary greatly. To get the exact
price, you need a complete quotation.
However, we can see the price you can expect to pay. We can also see
what you might save and produce as part of the RHI program.
Installation cost of air to water heat pump:
Taking into account the estimates proposed by the Energy Saving Trust
Fund (EST), it is assumed that the installation cost of the air-to-water heat
pump will vary between £7,000 and £11,000.
However, the installation of the heat pipe system is not a complicated
process because it usually only lasts a few hours, and it is recommended to
avoid installing the heat pipe by yourself. It is replaced by the help of
professional installers, because the heating efficiency largely depends on the
output of the heating system, which may be negatively affected if the system is
installed incorrectly.
Operating cost of air to water heat pump:
The operating cost of a heat pump depends largely on the COP of your
house, installation, and heat pump.
For a house of 100 square meters, the heating demand per square meter is
55 kilowatt-hours, which requires about 5,000-6,000 kilowatt-hours of heating a
year. In addition, considering that there are 4 people living in the house, the
hot water needs about 4,000 kWh.
If the outdoor temperature level is higher than 7 degrees Celsius, a
properly installed air-water heat pump that provides space heating may only
ensure a COP (Coefficient of Performance) of 3. Given that the average
temperature in the country between November and March varies between 4 and 7
degrees Celsius, the pump will consume approximately 2,200 kWh of electricity
at a cost of 285 pounds to produce 6,000 kWh of heating.
Nevertheless, in addition to £285 for space heating, we must also
consider the cost of hot water at 4,000 kWh. Similarly, if the water pump is
set up correctly, it will try to increase the water temperature to 30-35°C, and
then the built-in water heater can further increase the water temperature to
the desired level.
This symbiosis function of air to water heat pump and electric water
heater helps to keep the COP of the pump as high as possible and minimize the
work of the water heater, which helps you save on efficiency and cost.
Therefore, the cost of heating water is approximately £460. All these
add up to our total operating costs of £745-annual operating costs reduced by
3-4% (compared to condensing boilers) and 40% (compared to oil boilers),
provided that the COP of the heat pump is as high as possible Stay high for a
long time. This is because a new condensing gas boiler (85% efficiency) will
cost about 770 pounds per year to meet the same heating demand, while an
oil-fired boiler operating at the same efficiency will cost about 1,050 pounds
per year.
Types of air to water heat pumps:
1. Ductless, only need a 3-inch hole through the wall to connect the
outdoor condenser and the indoor head
2. Ducted, you need to install a duct system or use your existing
ventilation system
3. Short-run ducted, using a traditional large-scale duct system, only
passing through a small part of the house, usually supplemented by other
ductless units for the rest of the house
4. Split type, outside of the inner coil, the return air duct is
connected to the indoor central fan
5. Packed, usually with coils and fans outdoors, and the heated or
cooled air is transported to the inside from the pipe system passing through
the wall or roof
6. Multi-zone, connect two or more indoor heads to an outdoor condenser,
each head creates its own comfort zone, allowing families to heat or cool a
single room, corridor and other areas
7. Single zone, suitable for a single room with an outdoor condenser and
an indoor machine head matching
