Ground Source Heat Pumps Manufacturers
Leomon Technology is one of the most professional ground source heat
pumps manufacturers in China. We specialize in the production of various heat pumps
and have more than 20 years of experience in the refrigeration and heating
industry.
Our heat pump only selects the best components from
well-known companies such as Daikin, Sanyo, and Mitsubishi. Our ground source
heat pump has CE & RoHS approval.
Ground source heat pump is a more renewable and environmentally friendly
way of heating homes. They collect natural heat from the ground around your
property and use it to provide heating and hot water for your home.
By using natural, renewable resources, ground source heat pumps and
cooling systems can help you reduce your carbon footprint and lower energy
bills.
Heat pumps can be a highly efficient way of space heaters,
which usually generate about 3-4 kilowatts of heat per kilowatt of electricity
running. It can help you save up to 50% on heating costs.
Heat pumps are very stable and reliable. They can work all
year round and even provide cooling in summer.
Ground Source Heat Pump Features :
1). The reliability and outstanding performance of the world-renowned scroll compressor
2). Efficient and environmentally friendly R134A, R417A or R407C refrigerants, which do not destroy the ozone layer
3). Intelligent control: microprocessor digital controller with liquid crystal display
4). Adjustable water temperature: 25℃-60℃. No potential risk of contaminating drinking water
5). Blue hydrophilic aluminum fins, anti-corrosion, durable, low maintenance
6). Multiple protections to protect the compressor and heat exchanger
7). Internally threaded copper tube, higher efficiency
8). Alco or Danfoss thermal expansion valve can more accurately control pressure and temperature to ensure anti-fatigue and prolong service life.
9) Safety: Water and electricity are completely isolated, and there are no potential hazards such as flammability, gas poisoning, explosion, fire, electric shock, etc. related to other heating systems
Warranty:
1). Passed CE and RoHS certification
2). Service life is about 20 years
3). 2 years warranty, buy with confidence
Ground Source Heat Pumps Specifications:
Power capacity: 8kW, 10kW, 12kW, 15kW, 17kW, 20kW, 25kW, 28kW, 30kW, 35kW, 40kW, 45kW, 55kW, 60kW, 90kW, 100kW, 115kW, etc
Product model |
LM020-DFXRS-S |
Heating capacity |
8.2kw |
Input power |
1.9kw |
Rated current |
2.5A |
COP |
4.32 |
Rated outlet hot water temperature |
55℃ |
Highest outlet hot water temperature |
60℃ |
Production capacity |
176L/H |
Hot water Pipe size |
DN20mm |
Heat source inlet water temperature |
15℃ |
Heat source outlet water temperature |
10℃ |
Heat source circulation water capacity |
2000L/H |
Heat source pipe size |
DN20mm |
IP Grade (Level of protection) |
IPX4 |
Anti-electric shock Rate |
I |
Noise |
≤48dB(A) |
Net weight |
80kg |
Gross weight |
85kg |
Metel plate |
Galvanized steel/Spray/Gray |
Body size(W*D*H) |
650*450*650 |
Packing size(W*D*H) |
750*550*850 |
Loading quantity (20GP/40GP/40HQ) |
60/120/180 |
Compressor |
Panasonic |
Refrigerant |
R410A |
Power supply |
220V/50Hz |
Condenser |
Plate |
Evaporator |
Plate |
Expansion valve |
Danfoss /Emerson |
AC contactor |
(220V-18A) |
Thermorelay |
(12-18A)*1 |
Controller |
DF1SS-TS5(Motorola Chip) |
Low-voltage switch |
0.15/0.32MPa |
High-voltage switch |
3.0/3.6MPa |
Power line connect with unit |
3*2.5mm |
Package |
Polywood packing |
