Description
The heat pump uses electricity to capture the heat in the air and transfer it to the swimming pool. The heat pump pool heater is environmentally friendly and has high heating efficiency. It is the best choice for home, hotel or entertainment pool heaters.
The cop of the air source heat pump is as high as 4.5. Compared with gas heaters and electric heaters, it will save you 75% of the electricity.
The swimming pool heat pump can cool the swimming pool in summer and heat the swimming pool in winter. Provide a year-round comfortable water temperature for your swimming pool. Let swimming be your best way to relax.
Because the heat pump needs to absorb heat from the outside air. For those who use the swimming pool in warm weather and do not live in a cool climate, a heat pump may be the ideal choice.
Heat Pump Swimming Pool Heaters Features:
1. Copeland scroll compressor has high efficiency, low noise and long life.
2. Internally threaded copper and hydrophilic aluminum foil heat exchanger
3. Titanium material, corrosion resistant, specially used for swimming pool water.
4. The electronic expansion valve automatically adjusts the refrigerant flow.
5. Galvanized steel sheet, beautiful appearance and anti-corrosion.
6. Using PID defrosting technology, automatic defrosting.
7. Set and check all parameters, if the heat pump fails, it will protect itself.
8. The heat pump uses environmentally friendly refrigerants: R417A / R407C / R404A.
9. The heat pump is small in size, so ordinary plumbers can easily install it
10. Wide range of applications: swimming pools, hotels, hotels, beauty salons, saunas, etc.
Heat Pump Key Componets:
Smart control: microprocessor-based digital controller with LCD display digital controller
American Compressor: Copeland Scroll has high working efficiency.
Japan Saginomiya four way control valve: No back flow and block.
Axial Fans: high wind and low noise
Eco-friendly Refrigerant: without ozone depletion
PVC Titanium Heat Exchanger: resistance to chemical corrosion and pool corrosion
Warranty:
1. CE, CB, RoHS, Conform to EN14511-2:2011 test standard, ISO9001, ISO14001.
2. 2 years warranty
3.1% spare parts are repaired free of charge.
Leomon Technology Service:
Leomon Technology provides customized services. We can design and produce swimming pool Heat Pumps according to customers' special requirements.
Heat Pump Swimming Pool Heaters specifications:
| Heat Pump Swimming Pool Heaters | |
|
Model |
LMP-015 |
|
Rated heating capacity |
5.5kW |
|
BTU |
18771 |
|
Rated input power |
0.99kw |
|
Rated heating input current |
4.5A |
|
COP |
5.2KW |
|
Max running current |
7.0A |
|
Power source |
220V/50Hz |
|
Noise level |
40dB(A) |
|
Width |
750mm |
|
Depth |
300mm |
|
Height |
510mm |
|
Weight |
65kg |
|
Water temperature control precision |
±2℃ |
|
Working environment |
-15℃~43℃ |
|
Throttle type |
Electronic expansion valves |
|
Refrigerant |
R417A, R407C,R410A |
|
Compressor |
hitachi |
|
Compressor |
1Pcs |
|
Heat exchange type |
Efficient finned tube exchanger |
|
Motor power fan type |
Axial flow fan |
|
Motor power |
0.1kw |
|
Heat exchanger |
High titanium tube heat exchanger |
|
Water flow |
1.9m3/h |
|
Water pressure drop |
10kPa |
|
Connect pipe size |
1Inch |
|
Water size max work pressure |
600kPa |
Heat Pump Swimming Pool Heaters Applications:
Heat Pump Swimming Pool Heaters Installations:
Heat Pump Swimming Pool Heaters Connection Diagram:
