Description
The EVI
air source heat pump is designed for heating and cooling of domestic/commercial
residences in cold regions with minimum temperatures above -25°C.
1. High
efficiency and energy saving
The air
source heat pump can freely absorb the heat energy in the air, and the electric
energy is only used to drive the compressor to extract the heat in the air.
Therefore, it only consumes a quarter of the traditional electric heater,
saving users a lot of electricity bills.
2.
Environmentally friendly
Using air thermal energy and electricity, the heat pump does not emit harmful gases during operation.
3.
Available 24/7
All-weather
operation: stable operation, not affected by any wind, rain and snow.
4.
Durable
Copeland
compressors feature Enhanced Vapor Injection (EVI) technology with crankcase
heaters for use in special cold regions, and heat pump brand components such as
Danfoss electronic expansion valves, Eaton AC contactors and thermal relays
guarantee high quality and long life. All our screws and clips (external and
internal) are stainless steel. The cabinets we use are made of galvanized
steel, making them more rust-resistant, durable and affordable.
5.
Multiple protection
For
example, if the system water flow is insufficient, the system will display high
pressure protection and automatically stop the heat pump to protect the compressor
from damage. There is also high current protection: if the power supply is
unstable, the heat pump will display a high current error, stop the heat pump,
and avoid damage to the compressor.
6.
Linkage function
External
signal on/off function
7. Guaranteed
security
Water
and electricity are completely isolated to avoid electric shock, explosion and
poisoning; LCD digital controller runs automatically
8.
Convenience
EVI heat
pumps are easy to install in many places such as garages, balconies, kitchens,
etc.
Specifications:
Heating
output: 20Kw
COP 20°C-50°C: ≥4
Continuous
power/maximum A: 6.9/9.2
Voltage:
415V
Water
output L/h: ≥500
Noise
decibel (A): ≤50
Dimensions
(LxWxH) (mm): 1110x420x1250
Weight
(kg): 205
Fuse
rating (A): 30A
Flow
m3/H: 5300
Refrigerant:
R410a refrigerant
Output water temperature C: 58
