Description
A reversible air source heat pump is an energy-efficient heating and cooling device. Integrated conditioning enables winter heating and summer cooling via fan convection and panel heating. In cooling operation, the integrated additional heat exchanger directly uses the waste heat as free energy for domestic hot water and swimming pool water production. A particularly high coefficient of performance (COP) can be achieved when the waste heat from cooling operations can be used continuously (for example, to preheat a production process).
Features:
1.
Maximum flow temperature in heating operation 56°C
2.
Minimum flow temperature for cooling 9°C
3.
Heated external temperature operating limit -25°C to 40°C
4. Cool
10°C to 45°C
5.
Completely soundproofed compressor housing with electronically controlled fans
and naturally quiet operation
6.
Provisions that combine fan convection and silent cooling through floor, wall
and ceiling surfaces
7. With
dew point monitoring
8.
Integrated thermal energy meter
Technical
Specifications:
Colour/Finish/Material:
White aluminium (similar to RAL 9006)
Heat
Output (kW): 23.6kW @ A2/W35
Heat
Pump CoP: 3.70
Aspect
Height
(mm): 2100.00
Depth
(mm): 980.00
Width
(mm): 1735.00
Weight
(kg): 595.00
Additional
features
Power supply: 400V
